Revolutionary Socket for measuring torque directly on the bolt. RAD Smart Sockets are torque tool measurement devices for inspecting bolted joints. Also functions as a master calibration for torque equipment.
Instant torque readout on your live applications.
View and download logs onto your Smartphone or tablet
Part No.: 22002 – Smart Socket Model: 33mm – Torque (L-H): 150-1500 ft/lbs. – Drive Size: .75″ – Weight: 3.2 lbs – Height: 3.94″ – Diameter: 2.83″
Part No.: 21363 – Smart Socket Model: 36mm – Torque (L-H): 150-1500 ft/lbs. – Drive Size: 1″ – Weight: 2.65 lbs – Height: 3.94″ – Diameter: 2.83″
Part No.: 22158 – Smart Socket Model: 41mm – Torque (L-H): 150-1500 ft/lbs. – Drive Size: 1″ – Weight: 2.65 lbs – Height: 3.42″ – Diameter: 2.83″
Part No.: 20880 – Smart Socket Model: 46mm – Torque (L-H): 150-1500 ft/lbs. – Drive Size: 1″ – Weight: 2.65 lbs – Height: 3.42″ – Diameter: 2.83″
Part No.: 20881 – Smart Socket Model: 50mm – Torque (L-H): 300-3000 ft/lbs. – Drive Size: 1″ – Weight: 3.42 lbs – Height: 3.52″ – Diameter: 3.39″
Part No.: 20882 – Smart Socket Model: 55mm – Torque (L-H): 300-3000 ft/lbs. – Drive Size: 1″ – Weight: 3.2 lbs – Height: 3.52″ – Diameter: 3.39″
Part No.: 20883 – Smart Socket Model: 60mm – Torque (L-H): 300-3000 ft/lbs. – Drive Size: 1″ – Weight: 3.63 lbs – Height: 3.52″ – Diameter: 3.39″
Part No.: 23690 – Smart Socket Model: 65mm – Torque (L-H): 800-8000 ft/lbs. – Drive Size: 1.5″ – Weight: 8.7 lbs – Height: 4.75″ – Diameter: 4.53″
Part No.: 20884 – Smart Socket Model: 70mm – Torque (L-H): 800-8000 ft/lbs. – Drive Size: 1.5″ – Weight: 8.7 lbs – Height: 4.75″ – Diameter: 4.53″
Part No.: 20885 – Smart Socket Model: 80mm – Torque (L-H): 800-8000 ft/lbs. – Drive Size: 1.5″ – Weight: 8.7 lbs – Height: 4.75″ – Diameter: 4.53″
Part No.: 25657 – Smart Socket Model: 90mm – Torque (L-H): 800-12000 ft/lbs. – Drive Size: 1.5″ – Weight: 12.8 lbs – Height: 5.15″ – Diameter: 4.53″
Part No.: 25658 – Smart Socket Model: 100mm – Torque (L-H): 800-12000 ft/lbs. – Drive Size: 1.5″ – Weight: 15.9 lbs – Height: 5.75″ – Diameter: 4.73″
22002
21363
22158
20880
20881
20882
20883
23690
20884
20885
25657
25658
Smart Socket Model
33mm
36mm
41mm
46mm
50mm
55mm
60mm
65mm
70mm
80mm
90mm
100mm
Torque (low-high)
150-1500 ft/lbs
150-1500 ft/lbs
150-1500 ft/lbs
150-1500 ft/lbs
300-3000 ft/lbs
300-3000 ft/lbs
300-3000 ft/lbs
800-8000 ft/lbs
800-8000 ft/lbs
800-8000 ft/lbs
800-12000 ft/lbs
800-12000 ft/lbs
Drive Size
.75 inch
1 inch
1 inch
1 inch
1 inch
1 inch
1 inch
1.5 inch
1.5 inch
1.5 inch
1.5 inch
1.5 inch
Weight
3.2 lbs.
2.65 lbs.
2.65 lbs.
2.65 lbs.
3.42 lbs.
3.2 lbs.
3.63 lbs.
8.7 lbs.
8.7 lbs.
8.7 lbs.
12.8 lbs.
15.9 lbs.
Height
3.94 inches
3.94 inches
3.42 inches
3.42 inches
3.52 inches
3.52 inches
3.52 inches
4.75 inches
4.75 inches
4.75 inches
5.15 inches
5.75 inches
Diameter
2.83 inches
2.83 inches
2.83 inches
2.83 inches
3.39 inches
3.39 inches
3.39 inches
4.53 inches
4.53 inches
4.53 inches
4.53 inches
4.73 inches
